26 HDVI5 Component Video Switch

27HDVI5 Component Video Switch

K.I.S.S.™ (Keep It Simple Serial!™)

Ze k to r ’s excl u s i ve K .I . S . S .™ (Keep I t Simple S erial™) p rotocol was de -

signed by engineers who h ave been controlling RS - 232 devices for

most of their c a reers a n d understand th e p i tfalls of a bad l y d esigned

pro t o col.

A few features of the K.I.S.S.™ protocol are:

A simple and l o g i c a l ly consistent command stru c ture.

Fu l ly bi- directional o p erations and can op e rated in b o th

a Master Slave mode (onl y resp o n d s when spoken to) , o r

in an Asynchronous mode ( s tate changes are sent as t h e y

occur).

All commands and respon s e s can optional l y use a checksu m

or a CRC-8 ch e c k code to insure re l iable communication s.

A command will a l ways generate a response! There are no

“timeout ” states as p a r t of the protocol. A timeout wil l a l-

ways i n d i cate some typ e o f physi c a l connecti o n error (loose

cable, extreme noi s e, etc.).

Co m m ands and responses h ave been de s i g n e d fo r s i mple

parsing in any langua g e.

Easy to test using a ter m inal, or terminal em u l a t i o n soft-

ware. (H yper term, Se c u reCR T, etc. )

A few features of the HDVI5 command set are:

A full feature d command set that g o e s far beyond simple

fro n t panel control operations! Allows full control over all

fe at u res of t h e HDVI5.

Fu l l notification o f s tate changes.

Th e abilit y to disable the f ront pa n e l, an d s till have fro nt

panel button presses se nt to t h e serial por t .

Th e abilit y to re a d all IR codes s e nt to t h e HDVI5 by any re -

mote, e ven t h o s e not used by the H D V I5. Use the HDVI 5 to

add IR control to any pro j ect!

Many more features, too numerous to list h e re...

For a full de s c r iption of K .I.S.S . ™ and a list of t h e commands sup -

por ted by the HDVI5, d ownl o a d the HDVI5 sup p l e mental manual at:

ww w. zektor. com / H D V I5/downloads.htm

•

Th e RS-232 o n t he HDVI5 is t h e same format as a PC-m o d e m , and

uses the same t ype cabl e a s a serial m o d e m wo uld, which is a sta n -

dard straight through cable. Do n o t u se a cable th at i s marked as a

“Null Mod e m” c a ble.

Th e HDVI5 can a l s o be used with a ny USB to R S -232 conve r s i o n

cable, these are all t y p ically straight through c a b l es.

Th e RS-232 p o r t is a female type D E -9 connec tor ( s o metimes mista k-

enly refe r re d to as a DB-9 con n e c tor) with t h e fo l l o w i n g pinout:

5 4 3 2 1

9 8 7 6

Pin d e f initions:

1 - No Connect 6 - No Connect

2 - TX 7 - No Connect

3 - RX 8 - No Connect

4 - No Connect 9 - No Connect

5 - GND

Th e por t setting s u sed by the HDVI5 a re:

Baudrate: 9600

Data Bits: 8

Stop Bits: 1

Parity: NONE

Th e communications protocol used is Zektor ’s exc lusive K . I . S .S.™

(Keep I t Simple S e r ial™) protocol.

e RS-232 Port
