30 HDMI5 Component Video Switch

31HDMI5 Component Video Switch

Relay Options (Cont'd)

Toggle and Momentary Relay Modes

If all chan nel LEDs are off, then the relay wil l no t be affec ted by

chan ging chan nels. Th e 'S EL' b utton is used to s witc h be t ween the

Togg l e M ode and the Mom enta r y M ode.

Toggle Mode

In the To ggle Mo de ( the blue 'SE L' LE D is lit ) th e rel ay wi ll to ggle

bet ween On a nd O ff eac h ti me t he re lay b utton is presse d. Al l relay

delay tim es a re ign ored i n th e Togg le M ode.

Use t he ' SEL' butt on to swi tch to the To ggle Mo de ( Blue

'SEL' LED lit ).

Momentary Mode

In the Mom enta r y M ode (the red 'SEL' LED is lit) the relay will ac -

tivate whe n it 's b utton is press ed, an d th en t urn its elf off aft er a

program med amou nt of tim e. Use the 'SE L' bu tton to sw itch to t he

Mom entar y M ode (the red ' SEL' LED is l it).

Use t he 'A1' a nd 'A2' butto ns to adj ust the amou nt o f ti m e

the relay i s ac ti ve be fo re tu rnin g it self off. The d elay t ime s

are i ndic ated by the top row of blu e LE Ds a nd co rresp ond

to th e foll owing tim es:

No L EDs lit = Sa me a s Togg le M ode

• On e le ft just ifie d LE D = 1/ 4 se conds

•• Two lef t j ust i fie d LE D s = 1/ 2 se conds

••• T h ree l ef t ju stif ied LEDs = 1 secon ds

•••• Fou r le ft just ifie d LE Ds = 5 secon ds

•••• • Five LEDs = 10 seco nds

••• • Fo ur r ight jus tifi ed L EDs = 30 s econ ds

•• • Three righ t ju stif ied LEDs = 1 min ute

• • Two ri g ht j usti fied LED s = 5 minu tes

• On e r ight just ifie d LE D = 10 minu tes

•

1 2 3 4 5 SEL A1 A2

Toggle Mode

1 2 3 4 5 SEL A1 A2

Momentary Mode

All chan nel LEDs are turn ed o ff.

The b lue 'SEL' LED is lit.

Del ay Ti mes are i g nored.

Blue LEDs indicate delay times.

A1 = Decrease delay

A2 = Increase delay

All chan nel LEDs are turn ed o ff.

The re d 'S EL' L ED i s li t.

Press Pwr Button to

exit setup mode.

Press Pwr Button to

exit setup mode.
